| editor's comments:-
when the Platinum drive was launched
a few years ago - it originally was a hybrid HDD with a RAM
SSD style caache. The current models in 2009 replace the HDD
segment with a flash SSD - thereby increasing IOPS, throughput
and reliability. |
|
|
******Platinum drive 2009 model!*******
|
DTS chip + 1GB DRAM Write back
Cache + 128GB Flash = Enterprise SSD with Low cost!
1) High performance
read/write speed 220MB/s +200MB/s
2) Extend life time (10 to 400 longer than Flash SSD)
3) Mandatory Access Control Option for High security
|
|
*Platinumhdd(R) 2009 model now start
to book the order! HDD capacity is 320GB to 500GB.
*Platinum chip + Flash SSD will be king of storage devise!
It perform any application with low initial cost per GB.
DRAM + Flash SSD model 64GB/ 128GB! 20,000 write IOPS and
21,000 read IOPS!
* Good fit for enterprise server and RAID. Vmware and multiple
client environment is best fit application. Simulation,
Data base, Exchange /e-mail servers! Also video streaming,
editing are good application! Moreover, you can obtain excellent
benefit with Platinum cache software. See NUST university
test result.
|
|
Platinum High Performance HDD
|
|
DTS, Inc. is pioneering a new category of drive with the
Platinum HDD. Formerly known as the MCell Drive, the Platinum
HDD combines 1GB of SDRAM cache with up to 200GB of conventional
storage to offer the performance benefits of solid state
at a reasonable price. There are built-in capacitors and
an intelligent UPS to ensure data in memory is written to
nonvolatile disk in the case of power failure.
Drives can be purchased individually or in a RAID server.
You can also use it in tandem with our C4 software to get
even better performance. Contact
us for more information.
Install the Platinum HDD into your server and start seeing
the difference now!
|
|
|
Key Advantages
Performance
- 10-100 times the transaction performance of traditional
HDD
(See Comparison)
Efficiency
- Uses 1/3 less energy than traditional 3.5” HDD
- Provides up to 8 times the data throughput of conventional
HDD
Data Integrity
- Includes a UPS within each unit to ensure your data
is safe in the event of a power failure
Durability
- Lasts up to 30% longer than regular HDD
Integration
- No new application software needed
- Compatible with any OS that supports SATA (Windows,
Mac, Unix, Linux)
- Can be used in conjunction with regular HDDs.
|
What's inside?
|
Specifications
|
Interface
|
SATA-2 / SATA-1
|
|
Capacity
|
80/120/160GB 320GB/500GB Flash SSD model 64GB/ 128GB/256GB
|
|
Spindle Speed
|
5400/7200 RPM
|
|
SD RAM Cache Size
|
1 GB
|
|
Cache Policy
|
Write-back after charged UPS
Write-through before charged
|
|
Transfer Rate
|
3Gbps / 1.5Gbps
|
|
Reliability
|
30% better than traditional HDD
250% Long life from original Flash SSD
|
|
UPS
|
Capacitors, unlimited life
|
|
UPS charge
|
90 sec.
|
|
Power Consumption (idle/load)
|
7 watt/14 watt
6watt/11watt
|
|
Warranty
|
3 years
|
|
|
Patent number
|
| US |
Application No:11084894 |
| JP |
Patent No:4131862 |
| CN |
Patent No:ZL 200510080591.9 |
| HK |
Open No:1084204A |
| EU |
Patent Application No:05 011 38.9 |
| |
|
|
